EPS Control Unit Connector B (6P)
| EPS Control Unit Connector B (6P) (female terminals) |
| Terminal number | Terminal sign | Description |
|---|---|---|
| 1 | VF-CAN B_L | F-CAN communication circuit |
| 2 | VF-CAN B_H | F-CAN communication circuit |
| 3 | Not used | --- |
| 4 | VF-CAN C_L | F-CAN communication circuit |
| 5 | VF-CAN C_H | F-CAN communication circuit |
| 6 | IG1_VSA/ABS | Power source for activating the system |
