Exploded View: 2

GHH688486Courtesy of HONDA, U.S.A., INC.

*1: With heated steering wheel

  1. Steering Wheel
  2. Spring
  3. Steering Body Cover
  4. Paddle Shifter + (Upshift Switch)
  5. Paddle Shifter - (Downshift Switch)
  6. Heated Steering Wheel Control Unit
  7. Steering Wheel Lower Garnish Assembly
  8. Steering Wheel Lower Garnish
  9. Steering Wheel Switch Garnish
  10. Audio Remote-HFL Switch
  11. ACC Combination Switch
  12. Heated Steering Wheel Switch
  13. Heated Steering Wheel Switch Garnish
