Removal Procedure

WARNING: This page is about a different car, the 2003 Oldsmobile Aurora. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the left sound insulator. Refer to CLOSEOUT/INSULATOR PANEL REPLACEMENT -- LEFT in Instrument Panel, Gages and Console.
  2. Rotate the stop lamp/ABS/shift lock switch (2) counterclockwise, then pull to remove the switch.
  3. Disconnect the electrical connector from the switch.
    Fig 1: Removing Stop Lamp Switch
    G01506928Courtesy of GENERAL MOTORS CORP.
