Signal Circuit Inspection
- Ignition "ON"
- Measure voltage between terminal 1 of the sensor harness connector and chassis ground.
Specification: Approx. 5V
- Is voltage within the specification?
Yes:
- Go to "COMPONENT INSPECTION " procedure.
No:
- Check the short to ground in signal circuit.
- Repair as necessary and go to "VERIFICATION OF VEHICLE REPAIR " procedure.
