Front Seat: Replacement: Notes

CAUTION: SRS components are located in this area. Review the SRS component locations, precautions, and procedures in the SRS article before performing repairs or service (see RESTRAINTS ).

NOTE:

The seat with a airbag is marked with a side airbag on the surface of the seatback. Because the component parts (seat back cover, cushion, etc.) of seats with and without airbags are different, make sure you install only the correct replacement parts.

Fig 1: Identifying Side Airbag On Surface Of Seatback
Courtesy of HYUNDAI MOTOR CO.
Do not repair any tears or frayed spots of the seat-back cover. If necessary, replace the seat-back cover.
Take care not to tear the seams or damage the seat covers.
Put on gloves to protect your hands.
