System Specifications

Timing chain auto tensioner bolt 9.80-11.76 Nm (1.0-1.2 kgf.m, 7.23-8.68 ft. lbs.)

Crankshaft pulley bolt 284.2-303.8 Nm (29.0-31.9 kgf.m, 209.76-224.22 ft. lbs.)
