Connecting Rod Bearing

Connecting Rod Bearing






Connecting Rod Bearing Cap

Reinstall the lower bearing and cap, and tighten the nuts.

Tightening torque 31.4 - 34.3 N.m (3.2 - 3.5 kgf.m, 23.1 - 25.3 lb-ft)

Reinstall the lower bearings and caps, then tighten the bolts.

Tightening torque 53.9 - 58.8 N.m(5.5 - 6.0 kgf.m, 39.8 - 43.4 lb-ft)
