Data Flow

Fig 1: Atm Shift Lock Control (AT) Data Flow Chart
G07256631Courtesy of HYUNDAI MOTOR CO.
  1. In L_IGN1 ON, C_InhibitP ON or C_InhibitN ON condition, if L_BrakeSW input is ON, O_ATMSOL output is ON to makes moving condition of SHIFT LEVER.
  2. In L_IGN1 ON, vehicle speed is less than 7KPH and C_InhibitD ON conditions, if L_BrakeSW input is ON, O_ATMSOL output is ON to makes moving condition of SHIFT LEVER.
    Fig 2: ATM Shift Lock Control (AT) Timing Chart
    G07256632Courtesy of HYUNDAI MOTOR CO.
