Repair Procedures: Removal

  1. Disconnect the battery (-) terminal.
  2. Remove the air intake hose.

    (Refer to Engine Mechanical System - "INTAKE AND EXHAUST SYSTEM REPAIR PROCEDURES ")

  3. Remove the intercooler outlet hose & pipe.

    (Refer to Engine Mechanical System - "INTERCOOLER REPAIR PROCEDURES ")

  4. Disconnect the ETC module connector.
  5. Disconnect the coolant hoses (A).
  6. Remove the installation bolts (B), and then remove the ETC module from the engine.
G16186112Courtesy of HYUNDAI MOTOR AMERICA
