With Consult-II

Turn ignition switch to "ON" position. (Do not start engine.)
Select "DATA MONITOR" mode for A/T with CONSULT-II.
Start engine.
Run engine for at least 2 consecutive seconds at idle speed.
If DTC is detected, go to "DIAGNOSTIC PROCEDURE ".

Fig 1: DATA MONITOR Mode Display For A/T With CONSULT-II (DTC P1704)
Courtesy of NISSAN MOTOR CO., U.S.A.
