Removal and Installation: Installation

Note the following, and install in the reverse order of removal.

• Surely clamp fuel hoses and insert hose to the length below.

  Fuel filler hose: 35 mm (1.38 in)

  The other hoses: 25 mm (0.98 in)

• Be sure hose clamp is not placed on swelled area of fuel tube.
• Tighten the clamp hand with the top mark until the mark is on the bolt head flange "A".
  Fig 1: Identifying Bolt Head Flange

  Courtesy of NISSAN MOTOR CO., U.S.A.
• To connect quick connector, refer to , "QUICK CONNECTOR ".
