TCM Inspection Table
Data are reference value and are measured between each terminal and ground.
TCM INSPECTION
| Terminal | Wire color | Item | Condition | Data (Approx.) | |
|---|---|---|---|---|---|
| 1 | R/W | Power supply (Memory back-up) | Always | Battery voltage | |
| 2 | R/W | Power supply (Memory back-up) | Always | Battery voltage | |
| 3 | L | CAN-H | - | - | |
| 4 | V | K-line (CONSULT-II signal) | The terminal is connected to the data link connector for CONSULT-II. | - | |
| 5 | B | Ground | Always | 0V | |
| 6 | Y/R | Power supply | - | Battery voltage | |
| - | 0V | ||||
| 7 | R/L | Back-up lamp relay | Selector lever in "R" position. | 0V | |
| Selector lever in other positions. | Battery voltage | ||||
| 8 | P | CAN-L | - | - | |
| 9 | GR/R | Starter relay | Selector lever in "N""P" positions. | Battery voltage | |
| Selector lever in "R""D" positions. | 0V | ||||
| 10 | B | Ground | Always | 0V | |
