Warning Method
The following table shows the alarm or warning methods with chime.
Meter display, "KEY" indicator or key slot illumination when the warning conditions are met.
WARNING METHODS REFERENCE WITH CHIME
| Warning/Information functions | "KEY" warning lamp | Combination meter display | Key slot illumination | Warning chime | ||
|---|---|---|---|---|---|---|
| Combination meter buzzer | Intelligent Key warning buzzer | |||||
| Intelligent Key system malfunction | Illuminate | - | - | - | - | |
| OFF position warning | For internal | - | - | - | Activate | - |
| For external | - | - | - | - | Activate | |
| P position warning | - | - | Activate | - | ||
| ACC warning | - | - | Activate | - | ||
| Take away warning | Door is open to close | - | Flash | Activate | Activate | |
| Door is open | - | Flash | - | - | ||
| Push-ignition switch operation | - | Flash | Activate | - | ||
| Take away through window | - | Flash | Activate | - | ||
| Intelligent Key is removed from key slot | - | Flash | - | - | ||
| Door lock operation warning | Request switch operation | - | - | - | - | Activate |
| Intelligent Key operation | - | - | - | - | Activate | |
| Key warning | - | Flash | Activate | - | ||
| Intelligent Key insert information | - | Flash | - | - | ||
| Engine start information | Ignition switch is ON position | - | - | - | - | |
| Ignition switch is except ON position | - | - | - | - | ||
| Steering lock information | - | - | - | - | ||
| Intelligent Key low battery warning | - | - | - | - | ||
| Key ID warning | - | - | - | - | ||
