Component Inspection (Condenser)
WARNING: This page is about a different car, the 2012 Infiniti M35h. However, it is still accessible from the selected car via links, so may be relevant.
- CHECK CONDENSER
- Turn ignition switch OFF.
- Disconnect condenser harness connector.
- Check resistance between condenser terminals as per the following.
Courtesy of NISSAN NORTH AMERICA, INC.
Terminals Resistance (MΩ) 1 and 2 Above 1 [at 25°C (77°F)] Is the inspection result normal?
YES: INSPECTION END
NO: Replace condenser.
