Display And Warning (BCI)

Vehicle condition/Driver's operation	Status of detection within detection area	Vehicle speed	Blind Spot Warning/Blind Spot Intervention indicator	Action	Indication on the combination meter
BCI system OFF Shift lever in reverse	-	-	OFF	-	Courtesy of NISSAN NORTH AMERICA, INC.
					System OFF
BCI system ON Engine running Shift lever in reverse	Vehicle is absent	-	OFF	-	-
	Vehicle is detected	0 km/h (0 MPH)	Blink	Buzzer sounds (single beep) Display frame is yellow	-
		8 km/h (5.0 MPH) or less	Blink	Buzzer sounds (3 times) Display frame is red Accelerator pedal is pushed upward NOTE: When accelerator pedal is depressed Brake operation NOTE: When accelerator pedal is released	-
BCI system malfunction	-	-	OFF	Beep Temporary switch (navigation display) is deactivated	Courtesy of NISSAN NORTH AMERICA, INC.
					Malfunction See Owner's Manual
When radar blockage is detected	-	-	OFF	Beep Temporary switch (navigation display) is deactivated	Courtesy of NISSAN NORTH AMERICA, INC.
					Unavailable Side Radar Obstruction
When the accelerator pedal actuator detects that the internal motor temperature is high.	-	-	OFF	Beep Temporary switch (navigation display) is deactivated	Courtesy of NISSAN NORTH AMERICA, INC.
					Unavailable High Accelerator Temperature

Under the following conditions, the BCI system will be turned off automatically, a beep will sound. The BCI system will not be available until the conditions no longer exist.

• When the accelerator pedal actuator detects that the internal motor temperature is high.
• When side radar blockage is detected.
