Information Display (Combination Meter): Indicator/Information

WARNING: This page is about a different car, the 2018 Infiniti Q60. However, it is still accessible from the selected car via links, so may be relevant.

Item	Symbol	Function
ASCD indicator	Courtesy of NISSAN NORTH AMERICA, INC.	For detail of ASCD function, refer to System Description .
	Massage: - - Km/h / - - MPH
Stop/Start status indicator	Courtesy of NISSAN NORTH AMERICA, INC.	Indicates the status of stop/start system operation. ON: Stop/start system ON. (Engine stopped) OFF: Stop/start system is OFF. (Engine restart or running) For detail of Stop/Start status indicator function, refer to System Description
	Massage: ON OFF
Stop/Start warning indicator	Courtesy of NISSAN NORTH AMERICA, INC.	Indicates the message when a malfunction is detected in stop/start system. For detail of Stop/Start warning indicator function, refer to System Description
	Massage: System fault
Stop/Start guidance indicator	Courtesy of NISSAN NORTH AMERICA, INC.	Indicates the message when the driver performs a dangerous operation shown below: Hood is opened. For detail of Stop/Start guidance indicator function, refer to System Description .
	Massage: Not available
	Courtesy of NISSAN NORTH AMERICA, INC.	Indicates the message when the driver performs an operation which can lead the driver in danger as shown above during stop/start system operation and the above "Not available" indication continues for 5 seconds. For detail of Stop/Start guidance indicator function, refer to System Description .
	Massage: Push engine start button
Fuel filler cap warning	Courtesy of NISSAN NORTH AMERICA, INC.	For detail of Fuel filler cap warning system, refer to System Description .
	Massage: Loose Fuel Cap
