Warning And Automatic Cancellation Display

Condition		Description	Display on ICC system display
Warning display	When the ICC system is malfunctioning	A chime sounds and the control is automatically canceled NOTE: Turn the engine OFF and restart engine. If there is no malfunction, it is possible to set the system	Speed control indicator/warning : Yellow Courtesy of NISSAN NORTH AMERICA, INC.
System cancel display	When the vehicle slows down more than 13 km/h (8 MPH) below the set speed When the parking brakes are applied When the clutch pedal is depressed for longer than approximately 8 seconds. When VDC (including the TCS) operates When a wheel slips	A chime sounds and the control is automatically canceled NOTE: The system will be in a standby, after the control is automatically canceled	Speed control indicator/warning : Gray Courtesy of NISSAN NORTH AMERICA, INC.

NOTE: When the ICC system is automatically canceled, the cancellation condition can be displayed on "WORK SUPPORT" of CONSULT (ICC/ADAS).
