For USA
CAUTION:
Always drive the vehicle in safe manner according to traffic conditions and obey all traffic laws.
*1: Depress the accelerator pedal until vehicle speed is 90 km/h (56 MPH), then release the accelerator pedal and keep it released for more than 10 seconds. Depress the accelerator pedal until vehicle speed is 90 km/h (56 MPH) again.
*2: Checking the vehicle speed with GST is advised.
- The time required for each diagnosis varies with road surface conditions, weather, altitude, individual driving habits, etc.
Zone A refers to the range where the time, required for the diagnosis under normal conditions*, is the shortest.
Zone B refers to the range where the diagnosis can still be performed if the diagnosis is not completed within zone A.
- When the fuel tank is fully filled," EVAP SYSTEM" on CONSULT may not indicate "completed".
*: Normal conditions refer to the following:
- Sea level
- Flat road
- Ambient air temperature: 20 - 30 deg.C (68 - 86 deg.F)
- Diagnosis is performed as quickly as possible under normal conditions.
Under different conditions [For example: ambient air temperature other than 20 - 30 deg.C (68 - 86 deg.F)], diagnosis may also be performed.
