Code 31 - Turbo WASTEGATE Control (Over Boost)
Code No. 31 will NOT set if either code No. 33 or No. 34 is present.
Fig 1: Flow Chart - Code 31, Turbo Wastegate Control (Over Boost)
Courtesy of ISUZU MOTOR CO.
