Cruise Control Servo: Service and Repair

Actuator Cable Diagram:

Removal
1. Disconnect the battery ground cable.




2. Remove the cruise actuator assembly (4).
- Disconnect the connector (3).
- Remove the cable end (1) from the throttle link (cruise control side).
- Loosen two fixing nuts (2).
- Remove three actuator assembly fixing screws.

Installation
To install, follow the removal steps in the reverse order, noting the following point:
- Take care not to bend the cable excessively.
