Circuit Diagram
Fig 1: Immobilizer Control System - Circuit Diagram
Courtesy of KIA MOTORS AMERICA, INC.
Fig 2: Immobilizer Control System - Connector Views
Courtesy of KIA MOTORS AMERICA, INC.
Courtesy of KIA MOTORS AMERICA, INC.
Courtesy of KIA MOTORS AMERICA, INC.
