Axle Shaft Assembly





SPECIFICATION

DRIVESHAFT+





BJ : Birfield Joint
UTJ : U-Type Tripod Joint

Inner : On transaxle side
Outer : On tire side
TIGHTENING TORQUE






LUBRICANTS
