Starting System: Troubleshooting

NOTE:
  • The battery must be in good condition and fully charged for this troubleshooting.
Fig 1: Battery Charging System Troubleshooting Flow Chart
G11783823Courtesy of KIA MOTORS AMERICA, INC.
