Repair Procedures: Replacement

WARNING: This page is about a different car, the 2020 Kia Niro. However, it is still accessible from the selected car via links, so may be relevant.

Information

Be careful as the tailgate may fall down on people when the lifts are removed. Have a helper hold the tailgate open, or use a secure method to hold it open.

  1. Using a screwdriver (A), lift up slightly the socket clips (B) of both ends on the lifter (D), and then remove the lifter from the bracket (C).
    G13350747Courtesy of KIA MOTORS AMERICA, INC.
  2. Push the socket of the lifter into the bracket for installation.

    Information

    Make sure the tailgate locks and opens properly and locks securely.
