Retrieving Codes

1. Turn ignition on. Turn cruise main switch on. If CRUISE indicator light comes on, leave ignition on and go to next step. If CRUISE indicator light does not come on, check cruise indicator light circuit. See TEST NO. 12 under CIRCUIT TESTS .
2. To retrieve codes, turn cruise main switch off. Connect Jumper Wire (09843-18020) between terminals Tc and E1 of Data Link Connector (DLC) No. 2, located under left side of instrument panel. See Figure. Observe CRUISE indicator light to see if any codes are displayed. See DIAGNOSTIC TROUBLE CODE (DTC) DEFINITION  table.
   • CRUISE Light Does Not Come On: See TEST NO. 11 under CIRCUIT TESTS .
   • CRUISE Light Flashes Steadily: No codes set ("normal" code).
   • CRUISE Light Flashes Codes(s): Go to appropriate code under DTC TESTS .

When finished, disconnect jumper wire and turn ignition off.
