Overhead Console: Installation

WARNING: This page is about a different car, the 2004 Chrysler Pacifica. However, it is still accessible from the selected car via links, so may be relevant.
  1. Position the overhead console in the vehicle.
  2. Connect the electronic module and the reading/courtesy lamps electrical connector.
    Fig 1: Installing Variance Settings
    G03571560Courtesy of DAIMLERCHRYSLER CORP.
  3. Position the overhead console and install the overhead console retaining screw, located in the storage bin. Torque the screw to 1.2 N.m (10 in. lbs.).
    Fig 2: Identifying Top View Of Overhead Console
    G03571561Courtesy of DAIMLERCHRYSLER CORP.
  4. Connect the negative battery cable.
