Circuit Description

WARNING: This page is about a different car, the 2004 Lexus LS 430. However, it is still accessible from the selected car via links, so may be relevant.

These DTCs are output when the driver's door power window regulator motor circuit is malfunctioning.

Fig 1: Jam Protection Limit Switch\Pulse Sensor Circuit On Driver Side Door - Circuit Description Chart
G01442922Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
