Accelerator Pedal ASSY (3MZ-FE (Normal Pedal)): Replacement

DISCONNECT ENGINE WIRE NO. 3 (BATTERY NEGATIVE TERMINAL)
REMOVE ACCELERATOR PEDAL ASSY
1. Disconnect the accelerator position sensor connector.
2. Remove the 2 bolts, then remove the accelerator pedal rod.

  Fig 1: Removing Accelerator Pedal Assy
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
INSTALL ACCELERATOR PEDAL ASSY
Torque: 5.4 N.m (55 kgf.cm, 48 in.lbf)
CONNECT ENGINE WIRE NO. 3 (BATTERY NEGATIVE TERMINAL)
Torque: 5.4 N.m (55 kgf.cm, 48 in.lbf)
SYSTEM INITIALIZATION (See PRECAUTION )
