Circuit Description

This circuit detects the angle and direction of steering and automatically transmits its signal to the skid control ECU and distance control ECU.

Fig 1: DTC U0126 Problem Symptom Diagnostic Chart

Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.
