Outer Rear View Mirror: Reassembly

  1. CONNECT MIRROR
    1. Connect the mirror connector.
    2. Attach the claws labeled A, and set the mirror to the mirror body.
    3. Push the mirror to attach the claws labeled B and set it.
      Fig 1: Identifying Mirror Connector
      G04065798Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
