DTC C1254/54 Pressure Switch Circuit: Description

WARNING: This page is about a different car, the 2008 Toyota FJ Cruiser. However, it is still accessible from the selected car via links, so may be relevant.

The accumulator pressure sensor is connected to the skid control ECU in the master cylinder solenoid.

Fig 1: Pressure Switch Circuit Diagram
G05579847Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
DTC DETECTING CONDITIONS AND TROUBLE AREAS REFERENCE

DTC No. DTC Detecting Condition Trouble Areas
C1254/54 Accumulator pressure sensor fault (Fluid pressure does not change when it should e.g. pump operates, brake pedal depressed/released).
  • Master cylinder solenoid (skid control ECU)
  • Hydraulic brake booster (accumulator pressure sensor)
  • Hydraulic brake booster (master cylinder pressure sensor)
