Cooling System (Mechanical): Cooling: Thermostat: Components

Fig 1: Thermostat Replacement Components With Torque Specifications (1 Of 2)
G04948173Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Fig 2: Thermostat Replacement Components With Torque Specifications (2 Of 2)
G04948174Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
