DTC P2118: Throttle Actuator Control Motor Current Range / Performance: Wiring Diagram
Fig 1: Identifying Throttle Actuator Control Motor Wiring Diagram
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
