Rear Power Window Switch RH Circuit: Wiring Diagram

WARNING: This page is about a different car, the 2011 Toyota Avalon. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Rear Power Window Switch RH Circuit - Wiring Diagram
GTY296041Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
