DTC P0112: Intake Air Temperature Circuit Low Input; DTC P0113: Intake Air Temperature Circuit High Input [12/2013 - ]: Wiring Diagram

Fig 1: Manifold Absolute Pressure / Barometric Pressure Circuit Wiring Diagram

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
