| Skid Control ECU Assembly |
Stereo Component Equalizer Assembly |
Vehicle speed signal |
CAN |
| ECM |
Stereo Component Equalizer Assembly |
Engine RPM signal |
| Accelerator pedal angle signal |
| Integration sports mode indicator signal |
| Shift position P signal |
| Shift position R signal |
| Shift position D signal |
| Shift position N signal |
| Sport mode indicator signal |
| Shift gear signal |
| ECO mode indicator signal |
| SNOW mode indicator signal |
| Integration sports mode signal |
| Under speed change signal |
| Gear position signal |
| Drive mode select signal |
| Main Body ECU (Multiplex Network Body ECU) |
Stereo Component Equalizer Assembly |
Trip count signal |
| Time count signal |
