Components [10/2016 - 09/2020]
Fig 1: Driving Support Buzzer Replacement Components [10/2016 - 09/2020]
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
*1
HOOD LOCK CONTROL LEVER SUB-ASSEMBLY
*2
LOWER INSTRUMENT PANEL FINISH PANEL SUB-ASSEMBLY
*3
NO. 1 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY
*4
SKID CONTROL BUZZER
