DTC B22E2: Sub Battery Module State of Charge (Overdischarge) [12/2017 - 10/2023]: Wiring Diagram

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

*a	Sub-battery Module Assembly	-	-
*1	Sub-battery (Hi)	*2	Sub-battery (Low)
*3	Sub-battery	-	-
