Components [10/2023 - ]

Fig 1: Millimeter Wave Radar Sensor Replacement Components With Torque Specifications [10/2023 - ]
GTY1232939Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
*1 LOWER RADIATOR AIR DEFLECTOR *2 MILLIMETER WAVE RADAR SENSOR ASSEMBLY
*3 RADIATOR COVER PLATE *4 UPPER RADIATOR SUPPORT SEAL
N.m (kgf/cm, ft.lbf): Specified torque - -
