Components [11/2017 - 11/2019]

Fig 1: Telephone And GPS Antenna (For Front Side) Replacement Components [11/2017 - 11/2019]
GTY825602Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Callout Description Callout Description
*1 DEFROSTER NOZZLE ASSEMBLY *2 NO. 1 HEATER TO REGISTER DUCT
*3 NO. 1 SIDE DEFROSTER NOZZLE DUCT *4 NO. 2 SIDE DEFROSTER NOZZLE DUCT
*5 NO. 3 HEATER TO REGISTER DUCT *6 TELEPHONE AND GPS ANTENNA ASSEMBLY
