Components [12/2017 - 08/2019]
Fig 1: Electrical Key Oscillator (For Front Floor) Replacement Components With Torque Specifications [12/2017 - 08/2019]
| Callout | Description | Callout | Description |
| *A | w/ Telematics Transceiver | - | - |
| *1 | DCM (TELEMATICS TRANSCEIVER) | *2 | FRONT NO. 2 CONSOLE BOX INSERT |
| *3 | NO. 1 CONSOLE BOX DUCT | *4 | NO. 1 INDOOR ELECTRICAL KEY ANTENNA ASSEMBLY |
| *5 | NO. 3 CONSOLE BOX MOUNTING BRACKET | *6 | SHIFT AND SELECT LEVER SUPPORT |
| N.m (kgf/cm, ft.lbf): Specified torque | - | - |
