Parts Location [08/2021 - 07/2022]: Illustration
| *A | w/ Power Back Door System | - | - |
| *1 | BACK DOOR LOCK ASSEMBLY WITH COURTESY LIGHT SWITCH | *2 | FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY (for RH) |
| *3 | FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY (for LH) | *4 | FRONT DOOR LOCK WITH MOTOR ASSEMBLY RH |
| *5 | FRONT DOOR LOCK WITH MOTOR ASSEMBLY LH | *6 | REAR DOOR COURTESY LIGHT SWITCH ASSEMBLY (for RH) |
| *7 | REAR DOOR COURTESY LIGHT SWITCH ASSEMBLY (for LH) | *8 | REAR DOOR LOCK WITH MOTOR ASSEMBLY RH |
| *9 | REAR DOOR LOCK WITH MOTOR ASSEMBLY LH | *10 | MULTIPLEX NETWORK DOOR ECU |
| *11 | KICK DOOR CONTROL SENSOR | *12 | DOOR CONTROL SWITCH |
| *1 | WIRELESS DOOR LOCK BUZZER | *2 | FRONT DOOR OUTSIDE HANDLE ASSEMBLY LH - ELECTRICAL KEY ANTENNA - LOCK SENSOR - UNLOCK SENSOR |
| *3 | FRONT DOOR OUTSIDE HANDLE ASSEMBLY RH - ELECTRICAL KEY ANTENNA - LOCK SENSOR - UNLOCK SENSOR |
*4 | ELECTRICAL KEY AND TPMS RECEIVER ASSEMBLY |
| *5 | BACK DOOR OPENER SWITCH | *6 | ELECTRICAL KEY ANTENNA (OUTSIDE LUGGAGE COMPARTMENT) |
| *7 | NO. 1 INDOOR ELECTRICAL KEY ANTENNA ASSEMBLY (INSIDE LUGGAGE COMPARTMENT) | *8 | NO. 1 INDOOR ELECTRICAL KEY ANTENNA ASSEMBLY (FRONT FLOOR) |
