Mil Lit/DTC In Memory With DRIVEABILITY Concerns (97-26-19)

Publication date: 1997-12-22
Reference number: 97-26-19
Supersedes refnos: 97-21-13

MIL LIT/DTC IN MEMORY WITH DRIVEABILITY CONCERNS

TECHNICAL SERVICE BULLETIN

Reference Number(s): 97-26-19, Date of Issue: December 22, 1997
Superceded Bulletin(s): 97-21-13, Date of Issue: October 13, 1997

CONDITIONS

HESITATION/SURGE - MIL ILLUMINATED - DIAGNOSTIC TROUBLE CODES (DTCS) P0133, P0135, P0141, P0153, P0155, P0161, P1130, P1131, P1132, P1137, P1138, P1150, P1151, P1152, P1157, P1158 STORED IN MEMORY - VEHICLES BUILT THROUGH 11/97

MALFUNCTION INDICATOR LAMP (MIL) - MIL ILLUMINATED - DIAGNOSTIC TROUBLE CODES (DTCS) P0133, P0135, P0141, P0153, P0155, P0161, P1130, P1131, P1132, P1137, P1138, P1150, P1151, P1152, P1157, P1158 STORED - VEHICLES BUILT THROUGH 11/97

ROUGH IDLE - MIL ILLUMINATED - DIAGNOSTIC TROUBLE CODES (DTCS) P0133, P0135, P0141, P0153, P0155, P0161, P1130, P1131, P1132, P1137, P1138, P1150, P1151, P1152, P1157, P1158 STORED IN MEMORY - VEHICLES BUILT THROUGH 11/97

STALL - LOW SPEEDS AND OR IDLE - MIL ILLUMINATED - DIAGNOSTIC TROUBLE CODES (DTCS) P0133, P0135, P0141, P0153, P0155, P0161, P1130, P1131, P1132, P1137, P1138, P1150, P1151, P1152, P1157, P1158 IN MEMORY - VEHICLES BUILT THROUGH 11/97

LAMP - MALFUNCTION INDICATOR LAMP (MIL) ILLUMINATED - DIAGNOSTIC TROUBLE CODES (DTCS) P0133, P0135, P0141, P0153, P0155, P0161, P1130, P1131, P1132, P1137, P1138, P1150, P1151, P1152, P1157, P1158 STORED - VEHICLES BUILT THROUGH 11/97

APPLICATION

Model(s): Ford Light Truck: 1997-98 Expedition, F-150, F-250 LD

1998 F-350

Lincoln-Mercury: 1998 Navigator

Bulletin No.: 97-26-19

Date: December 22, 1997

Calibration: 7-46D-R07, 7-46E-R07, 7-46F-R07, 7-46R-R07, 7-46T-R07, 7-46U-R07, 7-46F-R10, 7-46U-R10, 7-48J-R05, 7-48U-R05, 7-48J-R10, 7-48U-R10, 8-46D-R05, 8-46E-R05, 8-46F-R05, 8-46R-R05, 8-46T-R05, 8-46U-R05, 8-48J-R05

NOTE: This bulletin supersedes Technical Service Bulletin 97-21-13 dated October 13, 1997.

WARNING: This modification is authorized only for the listed engine. Performing this modification on other engine calibrations is unauthorized and could create liability under applicable federal or local laws.

ISSUE

The Malfunction Indicator Lamp (MiL) may illuminate on vehicles with a 4.6L or 5.4L engine, and one or more of the following concerns may be present:

MIL lamp on with Diagnostic Trouble Codes (DTCs): P0133, P0135, P0141, P0153, P0155, P0161, P1130, P1131, P1132, P1137, P1138, P1150, P1151, P1152, P1157, P1158
Rough idle
Engine miss
Hesitation/Surge
Buck/Jerk
Stall at idle
Near stall
Stall at low speeds

This may be caused by the Heated Exhaust Gas Oxygen (HEGO) monitor calibration not allowing enough time for proper monitoring.

ACTION

Reprogram the Powertrain Control Module (PCM) and replace the HEGO sensor(s). Refer to the following SERVICE PROCEDURE for details.

SERVICE PROCEDURE

Perform normal diagnostics as outlined in the 1997 Powertrain Control/Emissions Diagnosis (PC/ED) On-Board Diagnostics II (OBD II) Service Manual and repair as required.
If the concern still exists or no problems were found, reprogram the PCM using Service Bay Diagnostic System (SDBS) or New Generation Star (NGS) Tester. Refer to the following RECALIBRATION CROSS REFERENCE CHART for correct PCM calibration.
Replace the HEGO sensor(s) (F88Z-9F472-AB) as required.

NOTE: For 5.4L applications, dealers must also perform TSB 97-26-17 to install the drain tube on the lower A/C evaporator drain.

RECALIBRATION CROSS REFERENCE

Year/Engine Size	Old Calibration	Old Part Number (-12A650-)	New Calibration	New Part Number (-12A650-)
1997 - 4.6L	7-48J-R05 7-48J-R10 7-48U-R05 7-48U-R10	F75F-AEB F75F-AEC F75F-XB F75F-XC	7-48J-R10 7-48J-R10 7-48U-R10 7-48U-R10	F85F-TC F85F-TC F85F-UC F85F-UC
1998 - 4.6L	8-48U-R05 8-48J-R05	F85F-UB F85F-TB	8-46U-R10 8-48J-R10	F85F-UC F85F-TC
1997 - 5.4L	7-46D-R07 7-46E-R07 7-46F-R07 7-46F-R10 7-46R-R07 7-46T-R07 7-46U-R07 7-46U-R10	F75F-ZD F75F-UD F75F-ACD F75F-ACE F75F-AAD F75F-VD F75F-ADD F75F-ADE	7-46D-R07 7-46E-R07 7-46F-R10 7-46F-R10 7-46R-R07 7-46T-R07 7-46U-R10 7-46U-R10	F7PF-ADA F7PF-AEA F7PF-AFA F7PF-AFA F7PF-AGA F7PF-AHA F7PF-AJA F75F-AJA
1998 - 5.4L	8-46D-R05 8-46E-R05 8-46F-R05 8-46R-R05 8-46T-R05 8-46U-R05	F85F-AAB F85F-ZB F85F-ACB F85F-ABB F85F-VB F85F-YB	8-46D-R10 8-46E-R10 8-46F-R10 8-46R-R10 8-46T-R10 8-46U-R10	F85F-AAC F85F-ZC F85F-ACC F85F-ABC F85F-VC F85F-YC

NOTE: PCM replacement is not authorized by this TSB. Refer to the Powertrain Control/Emissions Diagnosis (PC/ED) Service Manual for appropriate diagnostic procedures if PCM hardware concerns exist.

Obtain an Authorized Modification Decal (FPS 8262 - obtainable through DOES II, 25/pkg) and list the date, dealer number, and summary of modifications performed. See Fig 1 . Select a prominent place adjacent to the Vehicle Emission Control Information Decal suitable for installing the Authorized Modifications Decal Clean the area, install the decal, and cover it with a clear plastic decal shield.

PARTS INFORMATION

Part Number	Part Name
F88Z-9F472-AB	Heated Exhaust Gas Oxygen (HEGO) Sensor

WARRANTY INFORMATION

WARRANTY STATUS: Eligible Under The Provisions Of Bumper To Bumper Warranty Coverage And Emissions Warranty Coverage.

OPERATION: 972619A

DESCRIPTION: Reprogram Powertrain Control Module (PCM).

TIME: 0.2 Hr.

OPERATION: 972619DL

DESCRIPTION: Replace Heated Exhaust Gas Oxygen (HEGO) Sensors - 5.4L Left Side.

TIME: 0.3 Hr.

OPERATION: 972619DR

DESCRIPTION: Replace Heated Exhaust Gas Oxygen (HEGO) Sensors - 5.4L Right Side.

TIME: 0.6 Hr.

OPERATION: 972619DT

DESCRIPTION: Replace Heated Exhaust Gas Oxygen (HEGO) Sensors - 5.4L Both.

TIME: 0.8 Hr.

OPERATION: 972619ET

DESCRIPTION: Replace Heated Exhaust Gas Oxygen (HEGO) Sensors - 4.6L Both.

TIME: 0.4 Hr.

OPERATION: 972619E

DESCRIPTION: Replace Heated Exhaust Gas Oxygen (HEGO) Sensors - 4.6L One.

TIME: 0.3 Hr.

DEALER CODING: BASIC PART NO.: 9F472

CONDITION CODE: 42

OASIS CODES: 607000, 607400, 607700, 608000, 608400, 611000,

611500, 612000, 698298

Fig 1: Authorized Modification Decal
