Front Auxiliary Climate Control Assembly
WARNING: This page is about a different car, the 2004 Lincoln Navigator and 2004 Ford Expedition. However, it is still accessible from the selected car via links, so may be relevant.
Courtesy of FORD MOTOR CO. FRONT AUXILIARY CLIMATE CONTROL ASSEMBLY RESISTANCE SPECIFICATIONS
| Resistance between pins |
Resistance Range (approx.) |
| 3 and 9 |
50 ohms (WARM)-3,000 ohms (COOL) |
| 3 and 10 |
50 ohms (COOL)-3,000 ohms (WARM) |
