Plenum Chamber, Assembly and Components

WARNING: This page is about a different car, the 2003 Lincoln Aviator. However, it is still accessible from the selected car via links, so may be relevant.

Remove the defroster duct. For additional information, refer to AIR DISTRIBUTION DUCTS .
Remove the climate control assembly. For additional information, refer to CLIMATE CONTROL ASSEMBLY .
Remove the components in the order indicated in the following illustration.
To install, reverse the removal procedure.

Fig 1: Removal Sequence Of Plenum Chamber And Components
Courtesy of FORD MOTOR CO.
