Transmission Range Control Module (TRCM): Installation

Courtesy of FORD MOTOR COMPANY

Courtesy of FORD MOTOR COMPANY

Courtesy of FORD MOTOR COMPANY

4.

Position the selector lever cable, install the clip and the bolt, and connect the selector lever cable to the TRCM.
Torque: 62 lb.in (7 Nm)

Courtesy of FORD MOTOR COMPANY

5.

Position the degas bottle and the degas bottle hose and attach the retainers.

Courtesy of FORD MOTOR COMPANY

6.

Adjust the selector lever cable. Refer to: Selector Lever Cable Adjustment .
