Intake Manifold

Legend
1. Throttle and dynamic chamber
2. Exhaust absorber plate
3. Exhaust manifold and insulator
4. Fuel injectors and delivery pipe
5. Manifold oil nozzles and metering oil tubes
6. Intake manifold
7. Housing oil nozzles and metering oil tube
8. Metering oil pump
9. Water pump
10. Engine harness and vacuum piping
