Key Interlock System/Shift-Lock System

Fig 1: Key Interlock System/Shift-Lock System Wiring Diagram (H-2; 1 Of 2)
G11559930Courtesy of MAZDA MOTORS CORP.
Fig 2: Key Interlock System/Shift-Lock System Wiring Diagram (H-2; 2 Of 2)
G11559931Courtesy of MAZDA MOTORS CORP.
