Primary Shaft Components Assembly
PRIMARY SHAFT COMPONENTS ASSEMBLY1. Assemble in the order shown in the figure.
STANDARD TYPE
Primary Shaft Components Assembly (Standard Type):
DOUBLE CONE SYNCHRONIZER TYPE
Primary Shaft Components Assembly (Double Cone Synchronizer Type):
