DTC P0564: Notes

DTC P0564 DETECTION CONDITION AND POSSIBLE CAUSES

DTC P0564 Cruise control switch circuit malfunction
DETECTION CONDITION
  • The PCM monitors the cruise control switch signal at PCM terminal 1 AD. If the PCM detects that any one of following switches (Main, CANCEL, SET/COAST, RESUME/ACCEL) remains on for 2 min  , the PCM determines that the cruise control switch circuit has a malfunction.

    • Diagnostic support note

  • This is a continuous monitor (Other).
  • The MIL does not illuminate.
  • FREEZE FRAME DATA is not available.
  • DTC is stored in PCM memory.
POSSIBLE CAUSE
  • Cruise control switch malfunction
  • Connector or terminal malfunction
  • Short to power circuit in wiring from cruise control switch terminal A and PCM terminal 1AD
  • Short to body ground circuit in wiring from cruise control switch terminal A and PCM terminal 1 AD
  • PCM malfunction
G04315724
